| Designation |
Signal |
Description |
| 1.Type |
THR
THP |
Overload
Protection
Phase-Failure Protection |
| 2.Model |
1
2
3 |
for
Tc11&TC16
for TC21
for T30/35&40 |
| 3.Number of Heaters |
2
3 |
2Heater Elements
3Heater Elements |
| 4.Heater
Setting Range(A) |
0.12
0.2
0.3
0.44
0.6
0.8
1
1.2 |
0.1 - 0.12
- 0.15
1.15 - 0.2 - 0.24
0.24 - 0.3 - 0.36
0.36 - 0.44 - 0.54
0.48 - 0.6 - 0.72
0.64 - 0.8 - 0.96
0.8 - 1 - 1.2
0.95 - 1.2 - 1.45
|
| 1.8
2.1
2.8
3.6
5
6.5
7.5
|
| 1.4 |
- |
1.8 |
- |
2.2 |
| 1.7 |
- |
2.1 |
- |
2.6 |
| 2.2 |
- |
2.8 |
- |
3.4 |
| 2.8 |
- |
3.6 |
- |
4.2 |
| 4 |
- |
5 |
- |
6 |
| 5 |
- |
6.5 |
- |
8 |
| 6 |
- |
7.5 |
- |
9 |
|
9
11
15 |
7 - 9 - 11
9 - 11 - 13
12 - 15 - 18 |
19
23 |
16 - 19 - 22
20 - 23 - 26 |
28
33
40 |
22 - 28 - 34
28 - 33 - 38
32 - 40 - 48 |
